Tabletop Dry Cabinet – 151 Series

About the Tabletop Dry Cabinet – 151 Series

The XD-151 is a benchtop dry cabinet, or dry box, that is a compact high efficiency desiccant drying cabinet with 150L³ capacity. This benchtop dry cabinet is suitable for many differing applications encompassing electronics, laboratory, aerospace and any application requiring low controllable humidity storage. This system is designed to displace moisture from multiple substrates, materials and mediums, in turn rapidly returning the RH level automatically to the users desired set point on the LED control.

Desiccant Dry Cabinet – 150L³. As in all XDry enclosures the XD-151 contains auto desiccation technology to maintain an infinite range of set points from 50% to down to 2% RH. The internal sensor automatically controls the refreshing and recycling of the synthetic desiccant in the X133 drying unit. The synthetic regenerating desiccant for this dry box has a lifespan of up to 10 years creating a maintenance-free system with the operating cost of just pennies a day.

• X133 dryer system unit is self generating, auto-desiccated and maintenance free
• Closed loop programmable LED touch pad, which maintains RH% levels from 2 to 50% in .1% increments
• RH setting lockout on LED display insures no unauthorized changes to RH% set point
• Anti-corrosive & ESD safe coating on all surfaces, compliance with IEC61340-5-5
• Stainless steel shelves adjustable on 3″ intervals
• ESD wrist strap connection
• Secure lock and key mechanism
• Audible RH% Alarm alerts if RH% level is outside of set point

Specifications:

• RH Range 2% – 50% RH
• Available configured as AC110V, 50/60Hz OR AC220V, 50/60 Hz
• Electrical Consumption 30W Avg — 250W Max
• Capacity 150L³
• 3 Stainless Steel Shelves Included
• External Dimensions 500 mm x 630 x 580
• Internal Dimensions 490 mm x 560 x 530
• Weight 29 Kg

Options:

• Xtra-Heat
• RH/Cº data recorder
• HEPA filtration
• Alarm light tower
• Casters anchoring legs
• Additional dryer
• Sliding rail rack
• Custom engineering
• Nitrogen purge system
• Stainless steel construction
