Small Footprint Dry Cabinet – 302 Series
- Category: MSD Storage Cabinets
- Manufacturer: XDRY
Dry cabinet with a small footprint
- Set point from 2-50% RH ( +/-2%) maintained indefinitely
- Equipped with Internal sensor to control desiccant refreshing & recycling
- Energy Saving design
- Desiccant longevity exceeding 10 years
- Ergonomic Features
Twice as tall as our smallest unit and equipped with 2 doors and 7 standard shelves on adjustable 3” centers, this 122 cm (48”) tall dry cabinet maximizes storage space in a small footprint. The 302 Series is ideal for installation directly beside production equipment or in rework areas as well as laboratory environments. Additional shelves can always be added. Cabinet can be placed on casters to make it easily repositioned.
About the Small Footprint Dry Cabinet – 302 Series
The XD-302 is a compact high efficiency desiccant dry cabinet with 300L3 capacity. This small footprint dry cabinet storage system is suitable for many differing applications encompassing electronics, laboratory, aerospace and many applications requiring low controllable humidity storage.
This small footprint dry cabinet storage system, also called a dry box, is designed to displace moisture from multiple substrates, materials and mediums, in turn rapidly returning the RH level automatically to the users desired set point on the LED control.
This small footprint dry cabinet contains auto desiccation technology to maintain an infinite range of set points from 2% to up to 50 % RH. The internal sensor automatically controls the refreshing and recycling of the synthetic desiccant in the X133 drying unit. The synthetic regenerating desiccant has a lifespan of up to 10 years creating a maintenance-free system with the operating cost of just pennies per day.
- X133 dryer system unit is self generating, auto-desiccated and maintenance free
- Closed loop programmable LED touch pad, which maintains RH% levels from 2 to 50% in .1% increments
- RH setting lockout on LED display insures no unauthorized changes to RH% set point
- Anti-corrosive & ESD safe coating on all surfaces, compliance with IEC61340-5-5
- Stainless steel shelves adjustable on 3″ intervals
- ESD wrist strap connection
- Secure lock and key mechanism
- Audible RH% Alarm alerts if RH% level is outside of set point
Specifications:
- RH Range 2% – 50% RH
- Available configured as AC110V, 50/60Hz OR AC220V, 50/60 Hz
- Electrical Consumption 30W Avg — 250W Max
- Capacity 300L3
- 7 Stainless Steel Shelves Included
- External Dimensions 500 mm x 1230 x 640
- Internal Dimensions 490 mm x 1160 x 590
- Weight 29 Kg
Options:
- Xtra-Heat
- RH/Cº data recorder
- HEPA filtration
- Alarm light tower
- Casters anchoring legs
- Additional dryer
- Sliding rail rack
- Custom engineering
- Nitrogen purge system
- Stainless steel construction
